Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA PR1KCN40 - PR1KCN40
ϟ Product
details
Teltonika SKU: PR1KCN40

Teltonika 5G COMBO MOBILE/GNSS SMA ANTENNA PR1KCN40

$226.84

Price includes GST

In stock — ready to dispatch
Express delivery availableEnter your postcode for delivery options and cost
⌖
Australian warrantyLocal support for every product
↶28-day free returnsEasy change-of-mind returns
AMEXApple Pay Google Pay Mastercard PayPalShop Pay Union PayVisa
Australian warrantyLocal support, every order
Fast dispatchFrom our Australian warehouse
Genuine productsSourced from trusted brands
28-day free returnsShop with confidence
SHOP WITH CONFIDENCE

Support that continues after checkout

Clear delivery, warranty and returns information—without surprises.

Express deliveryAustralia-wide delivery options shown at checkout.
Australian warrantyLocal support with warranty coverage applicable to each product.
28-day free returnsEasy change-of-mind returns under our returns policy.
Secure paymentsProtected checkout with the payment methods you know.
Shipping and delivery+

Enter your postcode above for available delivery options. Final delivery timing and cost are confirmed during checkout.

Australian warranty support+

Products include Australian warranty support. Coverage and conditions depend on the product and manufacturer, so no fixed warranty duration is displayed.

Returns and refunds+

Change-of-mind returns are available subject to eligibility and the conditions in our returns policy.

Privacy and secure checkout+

Your checkout is processed securely by Shopify and the payment provider you select.

Read privacy policy →
DESCRIPTION ADDITIONAL INFORMATION REVIEWS

Technical Data Mounting type M6 Screw or Adhesive Enclosure material PC/PC+ABS UV resistant ✓ Cable length 3000 mm Weight 450 g Operating temperature -40 °C ~ +80 °C Operating humidity ≤ 90 % Ingress Protection Rating IP67 RoHS compliant ✓ 5G MOBILE MIMO ANTENNA Frequency range 600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz Polarisation Linear Radiation pattern type Omni-directional Gain ≤ 4 dBi V.S.W.R ≤ 2.5 Impedance 50 Ω Connector type and count 4 x SMA Male Cable type 4 x LMR100 GNSS ANTENNA Frequency range 1559 ~ 1610, 1164 ~ 1189 MHz Polarisation RHCP Radiation pattern type Directional Gain ≤ 2 dBi LNA Gain 17 ± 2 dB LNA noise figure ≤ 2 dB V.S.W.R ≤ 2 Impedance 50 Ω Supply voltage 3 ~ 5 VDC Current consumption 15 mA Connector type and count 1 x SMA Male Cable type 1 x LMR100

Product details

  • Brand: Teltonika
  • Manufacturer SKU: PR1KCN40
  • Category: Networking > Routers & Modems > IoT & LTE Networking

From the manufacturer

Brand: Teltonika
SKU: PR1KCN40
Barcode: 4779051847341
Weight: 0.58 kg
